1. DSP multi-purpose power amplifier with toroidal transformer;
2. 1.5U aluminum alloy panel, DSP pre-amp effect with CLASS D post-amp;
3. Music and vocals are independently equipped with 8-band parametric equalization adjustment, and 4-channel microphone input;
4. Configure 3 kinds of effect storage and modification functions;
5. Equipped with 5.0 Bluetooth and USB player interface, which can play lossless music;
6. Provide 4 microphone inputs, optical coaxial inputs, and 15m infrared remote control, which is convenient for engineering use;
7. SUB subwoofer output interface, pure music output interface, 5V1A power interface;
8. Built-in microphone automatic noise suppression circuit and feedback simulation circuit;
9. Double reverberation, reverberation, damping, pre-delay and other functions make the singing voice richer and more natural;
10. Professional-grade full electronic volume control, music pitch change and one-key factory reset
11. Perfect overheating, short circuit, DC and other speaker protection functions.
12. Equipped with temperature-controlled cooling fan to strengthen the heat dissipation of the machine and meet the long-term working requirements;
1. DSP multi-purpose power amplifier with toroidal transformer;
2. 1.5U aluminum alloy panel, DSP pre-amp effect with CLASS D post-amp;
3. Music and vocals are independently equipped with 8-band parametric equalization adjustment, and 4-channel microphone input;
4. Configure 3 kinds of effect storage and modification functions;
5. Equipped with 5.0 Bluetooth and USB player interface, which can play lossless music;
6. Provide 4 microphone inputs, optical coaxial inputs, and 15m infrared remote control, which is convenient for engineering use;
7. SUB subwoofer output interface, pure music output interface, 5V1A power interface;
8. Built-in microphone automatic noise suppression circuit and feedback simulation circuit;
9. Double reverberation, reverberation, damping, pre-delay and other functions make the singing voice richer and more natural;
10. Professional-grade full electronic volume control, music pitch change and one-key factory reset
11. Perfect overheating, short circuit, DC and other speaker protection functions.
12. Equipped with temperature-controlled cooling fan to strengthen the heat dissipation of the machine and meet the long-term working requirements;
| Model | K6+ |
| Stereo power 8Ω | 2*200W |
| Number of channels | 2 |
| Total harmonic distortion | 0.05% |
| Frequency response | 20Hz ~ 20KHz (±0.5dB) |
| Signal-to-noise ratio | ≥98dB |
| Enter sensitivity | Music 250mv / Mic 30mv |
| Input Impedance (Unbalanced/Balanced) | 22KΩ |
| Net weight of a single unit | 6.5KG |
| Gross weight of a single unit | 8KG |
| Single fuselage size | 430x220x65 (mm) |
| Packing size of a single unit | 480x340x110 (mm) |
| Two units in a pack size | 495x350x250 (mm) |
| Model | K6+ |
| Stereo power 8Ω | 2*200W |
| Number of channels | 2 |
| Total harmonic distortion | 0.05% |
| Frequency response | 20Hz ~ 20KHz (±0.5dB) |
| Signal-to-noise ratio | ≥98dB |
| Enter sensitivity | Music 250mv / Mic 30mv |
| Input Impedance (Unbalanced/Balanced) | 22KΩ |
| Net weight of a single unit | 6.5KG |
| Gross weight of a single unit | 8KG |
| Single fuselage size | 430x220x65 (mm) |
| Packing size of a single unit | 480x340x110 (mm) |
| Two units in a pack size | 495x350x250 (mm) |
| 名称 | 类型 | 大小 | 地址 |
|---|---|---|---|
| K+_AMPLIFIER | 下载 |
