1. Comparable to the imported power amplifier with first-class timbre, large dynamic and high-power CLASS D circuit power amplifier, with coil transformer, super stability and full power, greatly reducing intermodulation distortion and noise, is a new generation of excellent professional power amplifier
2. The timbre of imported power amplifier, super high sound value
3. Equipped with DC current (DC) protection, short circuit protection, current limiting voltage protection, temperature limiting protection and perfect horn protection function to ensure that the machine and horn can work normally for a long time.
1. Comparable to the imported power amplifier with first-class timbre, large dynamic and high-power CLASS D circuit power amplifier, with coil transformer, super stability and full power, greatly reducing intermodulation distortion and noise, is a new generation of excellent professional power amplifier
2. The timbre of imported power amplifier, super high sound value
3. Equipped with DC current (DC) protection, short circuit protection, current limiting voltage protection, temperature limiting protection and perfect horn protection function to ensure that the machine and horn can work normally for a long time.
Model | PT2.1400 |
Channel stereo power 8Ω | 2*1400W |
Number of channels | 2 |
Total harmonic distortion | 20Hz-20kHz 1W<0.075% |
Signal path separation (crosstalk) in | 1KHz)>70dB |
Signal-to-noise ratio | >100dBA |
Frequency response | 1W 8Ohm,20Hz-20kHz+/-0.05dB |
Damping control | >2000 |
Input impedance balanced/unbalanced | 20/10kohm |
gain | 0.775V 1V 1.4V |
Amplifier gain | 34dB |
gross weight | 22KG |
Product dimensions | 483x350x88 (mm) |
Packing size of a single unit | 560x440x150(mm) |
Model | PT2.1400 |
Channel stereo power 8Ω | 2*1400W |
Number of channels | 2 |
Total harmonic distortion | 20Hz-20kHz 1W<0.075% |
Signal path separation (crosstalk) in | 1KHz)>70dB |
Signal-to-noise ratio | >100dBA |
Frequency response | 1W 8Ohm,20Hz-20kHz+/-0.05dB |
Damping control | >2000 |
Input impedance balanced/unbalanced | 20/10kohm |
gain | 0.775V 1V 1.4V |
Amplifier gain | 34dB |
gross weight | 22KG |
Product dimensions | 483x350x88 (mm) |
Packing size of a single unit | 560x440x150(mm) |
